level measuring instrument tools 3 axis digital screen GCS900 3D and 3 pcs 1u 500mm linear encoder for milling/lathe machines

level measuring instrument tools 3 axis digital screen GCS900 3D and 3 pcs 1u 500mm linear encoder for milling/lathe machines
  • Продавецflimmer.com
  • Список ценUS $244.75piece
  • Продажная ценаUS $244.75piece
  • ДоставкаБесплатная доставка
  • Рейтинги4,4 (907)

Oписание продукта

70-470-1um
Product Brief:
KA-300 grating ruler is a kind of grating ruler which is widely used. It has reasonable structure,
The shape design is beautiful, good rigidity, can meet the majority of general machine tool users use, use long
Degree in 70~1020mm.
1. technical parameters
1.1, pitch:
1.2, resolution:
1.3, accuracy:
1.4, range:
0.02 mm (50 line /mm)
5 um, 1um, 0.5um
+ 3 um+ 5um + 15um m/m (20 + 0.1 C)
30~3000mm
1.5, moving speed: high speed ruler 120 m/min (need to be customized)
Ordinary ruler 60m/min
1.6, power supply:
+5V + 5%, 80mA
1.7, the length of the cable: Standard 3M (special length can provide according to the needs of the user)
1.8, working temperature: 0~45
1.9, plug foot instructions:
DB9-37-3
1) suitable for: 9 core socket RS-422 signal output.
-3

2) suitable for: 9 core socket TTL signal output.
TTL--3
FG: shielded metal case
3) suitable for: 7 core socket TTL signal output:
7TTL-3
4.1 mounting dimensions
Outline size of KA-300 grating ruler
KA3002
L0 is the effective measuring length of the ruler; L1 is the size of the mounting hole of the ruler; L2 is the size of the ruler.
-1um-1
-1
-2
KA3005KA3001KA3004KA3002KA3003
-1
