Oписание продукта






















Products Description

TTS RJ45 10/100M UTP Ethernet data traffic surge protector

Products Application
Applied to lightning region LPZ1-LPZ2 partition interface. TTS-RJ45-E100/4S protect a 10/100M Ethernet standard twisted-pair cable, RJ45-8E, 16E, 24E protection respectively 8, 16 and 24 10/100M Ethernet standard twisted-pair

Products Type
TTS-RJ45-E100/4S TTS-RJ45-24E TTS-RJ45-16E TTS-RJ45-8E

According to TIA / EIA 568 and ISO / IEC 11801 standard design, is five cable Ethernet structured cabling systems and other similar applications ideal surge protector. Provide high energy and low energy coarse-level protection for data lines fine protection to sensitive electronic equipment from damage. Products with good frequency transmission characteristics, high-pass flow and fast response speed, can be widely used in office and industrial premises 100M Ethernet network cabling and similar data communication systems. Interface in the form of products as the standard RJ45 interface, plug and play protection line 1,2,3,6, installation and maintenance is very convenient.
Product Features:
  1. network line surge voltage protection
  2.discharge current 5kA
  3.High-speed response
  4. low voltage limit
  5. RJ45 socket ends of the crystal
  6. 10/100M adaptive
  7. two pairs of ground lightning discharge circuit


Products Data



Type

AP 100M16

Nominal Voltage

Un

5V

Max.Continous operation voltage

Uc

8V

Rated current

IL

200mA

C2 line - the line between the nominal discharge current (8/20μs) L-L

In

100A

C2 Total nominal discharge current (8/20μs) L-PG

In

10kA

C2 line - between the ground Maximum discharge current (8/20μs) L-PG

Imax

2.5kA

C2 IN voltage protection level L-L

Up

≤15V

C2 IN voltage protection level L-PG

Up

≤600V

Insert Loss



0.5dB/100MHz

Max. Transfer speed

Vs

100M/s

Responce Time

tA

<1ns

Conventions protecting core wire



1/2,3/6

Protect Level



IP 20

Input / output interface



RJ45

Mounting rails



15mm/35mm*

Operation Temperature

T

- 40degree ~ + 80degree


Application and Maintenance



  AP 100M16 protect a 10/100M Ethernet standard twisted-pair cable is suitable for protecting a single computer or server, M16,M8,M24  protection respectively 8, 16 and 24 10 / 100M Ethernet standard twisted pair cabling standards applicable to lightning or other surge protectionCAT3, SWITCH CAT5 system, HUB, ROUTER and computer network equipment.


Product Installation
Integrated multi-stage surge protection, lightning can be used for regional LPZ1-LPZ2 partition interface with mounting accessories cables, which can be easily connected in series access line, pay attention to the direction of the cable out of the installation, there are "IN" and "OUT" sign. "IN" is always a non-protected side, and indicate the direction of voltage that may arise over the protection side "OUT" points to the protected area or equipment grounding conductor by equipotential connections should be installed as close to the equipment to be protected, and with the shortest ground paths. Ground path should be as short as possible, no longer than 1.5 meters. TTS-RJ45-E100/4S can be easily mounted on 15/35mm standard rail, AP M8, M16, M24 can be easily installed in standard 19-inch rack, occupying only 1U of space. Note that out of the surge protector should take when installing cable lines separated to avoid the emergence of a secondary coupling surge. During the installation will also be required to confirm whether the pin with a surge protector communication communications equipment used to protect the feet to match, or to change the wiring at the interface that jumper.
Product Maintenance
Should be checked regularly work surge protector, because if we find the cause of the surge protector reduces system transmission performance or signal interruption, the user is prompted lapsed protection circuit protector installed in the electronic device loses its protective effect downstream users must replace the protector immediately.
Order information
10/100M 16 Ethernet Network Protection, 19 "standard rack mount



Order information

Item

Type

Specification

shell material

*30001

TTS-RJ45-E100/4S

10/100M Single-port Ethernet network protection

Aluminum profiles

30002

TTS-RJ45-16E

10/100M 16 Ethernet Network Protection, 19 "standard rack mount

Sheet Metal

*30003

TTS-RJ45-24E

10/100M 24 Ethernet Network Protection, 19 "standard rack mount

Sheet Metal

30050

TTS-RJ45-8E

10/100M 8 Ethernet Network Protection, 19 "standard rack mount

Sheet Metal
