AT2511digital micro ohm meter Chrome nickel wire resistance

AT2511digital micro ohm meter Chrome nickel wire resistance
  • Продавец
  • Список ценUS $341.91piece
  • Продажная ценаUS $341.91piece
  • ДоставкаБесплатная доставка
  • Рейтинги4,7 (188)

Oписание продукта



Basic accuracy of 0.05%

Measuring range 10μΩ ~ 2kΩ
Source Maximum current:
Automatic and manual range nine Range
Measurement speed 30 times / second, 15 times / sec, 2 times / sec
Showing results direct reading, ΔABS, Δ% and sorting the results
The maximum reading of 20,000
Full scale calibration short correction, with the relative function REL
Display and output of the comparator NG-LO, GD-IN, NG-HI hearing sound
Trigger internal, manual, external, remote trigger
Interface Standard RS232C interface Handler Interface (PLC interface)
Test terminal 4 side shields (including two detection terminals and two drive end) and the outer shield ground terminal
Power Requirements Voltage: 198VAC ~ 240VAC Frequency: 50Hz Power: Maximum 15VA
Size and weight Overall dimensions (mm): 270mm (width) x130mm (height) x290mm (D) Weight: 4kg
Optional accessories 0.8 m four-terminal resistance fixture
Other 192 * 64 LCD
